Hybrid Sliding Patio Doors


Features & Benefits

Lux hybrid sliding patio doors feature a sleek, stylish design with a low-maintenance extruded metal exterior combined with our exceptional high-quality vinyl interior – the best of both worlds.

  • Extruded aluminum mainframe and panels offer greater structural capabilities for withstanding tough Alberta climates while eliminating the need for painting
  • Features steel reinforcing in all panels and interlocks, resulting in maximum durability and strength.
  • Customized jambs for renovations, new builds, ICF and log homes
  • Available in four brickmould size options; 5/8", 2", 3 1/2" new construction brickmoulds as well as our renovation brickmould.
  • Choose from eight signature colours, or customize with our aluminum clad exterior wood grain or a custom colour of your choice.
  • Add personality with our wide selection of SDLs and grill designs in a variety of sizes and colours
  • Our sleek frame design allows for more glass that lets natural light in, available in dual and triple-pane glass glazing options.
  • A number of standard sizes ranging from 5', 6' and 8' wide in a single slide application, as well as 10', 12' and 16' wide in a bi-parting configuration, all up to 8' tall – custom sizes available
  • Extruded integral nailing flange eliminates the risk of water and air infiltration between the nailing flange and the brickmould
  • Matching colour screens and optional foot locks for venting and security
  • Multi-point latch available in six finishes
  • 2 1/4" panels can accommodate both dual and triple-pane glass options for the ultimate energy-efficient performance

A Closer Look at our Hybrid Sliding Patio Doors

  1. Extruded Aluminum —offers greater structural capabilities to withstand the tough elements of nature and eliminates the need for painting. The aluminum is independently secured allowing the vinyl and aluminum to expand and contract without restriction.
  2. Endur IG™ ensures outstanding thermal performance and exceptional longevity. For more information about Lux glass and glazing options, see “Glass Performance.”
  3. Extruded integral nailing flange and corner gaskets, eliminating the risk of water and air infiltration between the nailing flange and the brickmould.
  4. Multi-chamber, heavy wall UV stable PVC extrusion provides thermal efficiency and colour stability. This multi-chamber design with thermal breaks not only is used to conserve heat but provide optimal stability.
  1. Steel reinforced panels and interlocks, fastened to the PVC for added stability and security.

Hybrid Sliding Patio Door Colours

Customize the exterior of your Hybrid Sliding Door with a colour perfectly suited to your home's unique palette. Choose from the eight Lux signature colour options below and instantly add curb appeal to any new home construction or renovation.

Colours may not be exactly as shown and are subject to change without notice.
Please contact a Lux consultant for details.

Hybrid Sliding Door Wood Grain Options

The character & style of real wood, but without maintenance headaches. Offering all of the warmth and style of real wood, but with the durability, weather resistance and low maintenance qualities of aluminum cladding. Lux's incredibly realistic wood grain finish offers homeowners the option to select a truly exceptional finish for their door exterior. Constructed of aluminum and suitable for all aluminum clad doors, but with the character of authentic wood, Lux's wood grain finishes add a distinctly natural feel to any exterior.

Colours may not be exactly as shown and are subject to change without notice.
Please contact a Lux consultant for details.

Multipoint Hardware

Multipoint hardware is designed to lock at several points throughout the height of the door making the lock side of the door as secure as the hinge side and provides an exacting seal around the perimeter of the door. Lux's hardware selections will add character and enduring value to every door in your home. Made of solid brass, each handle can be personalized with your choice of finishings to complement your personal style. All hardware is specially crafted to resist wear, and like the door itself, will last a lifetime.

hardware sytle options
Choose the hardware that best suits your personal taste:

hardware colour options
Customize your hardware with your choice of 9 colours:

Colours may not be exactly as shown and are subject to change without notice.
Please contact a Lux consultant for details.
